Netafim 2" MPT - Dual Lite Disc Filter for Lawn & Garden Irrigation
Product Overview
Clogged emitters and uneven distribution uniformity are the quickest ways to ruin a professional landscape installation; especially when peak summer heat arrives. When filtration fails, your crews face hours of manual flushing, costly nozzle replacements, and the risk of turf loss that can damage your reputation. Given current global supply chain fluctuations and high seasonal demand for filtration components, waiting until a system fails to order replacements often leads to weeks of downtime. Planning your inventory now ensures that your projects stay on schedule, your inspections pass on the first visit, and your clients remain satisfied with a system that performs flawlessly from day one.
The Netafim Dual Lite Disc Filter provides a significant technical advantage over standard screen filters by utilizing a deep, three dimensional filtration process. While screen filters can be bypassed by sharp debris or easily shredded under high pressure, these grooved plastic discs compress to trap organic and inorganic contaminants throughout the entire depth of the stack. This design drastically extends the intervals between cleanings, reducing your long term maintenance labor and protecting expensive downstream components like pressure compensated dripline and high efficiency rotors. Carrying these professional grade filters gives your business a competitive edge by offering a more robust, reliable solution compared to lower grade retail alternatives.
Product Specifications
| Specification | Detail |
|---|---|
| Brand | Netafim USA |
| Connection Size | 2 inch MPT (Male Pipe Thread) |
| Filter Type | Dual Lite Disc Stack |
| Material | Reinforced Polyamide / Polypropylene |
| Maximum Pressure | 115 PSI |
| Maximum Flow Rate | 80 GPM |
| Filtration Degree | 120 Mesh / 130 Micron (Standard) |
| Color | Black Housing with Red/Yellow Internal Components |
Available Models & Sizes
The Netafim Lite series is available in several configurations ranging from 3/4 inch for residential zones up to this 2 inch high capacity model for commercial headers. Standard disc grades include 80, 120, and 150 mesh to suit various water qualities. Please contact our sales team for bulk pricing or specific disc color configurations for unique water sources.
Key Features
- Depth filtration technology captures significantly more debris than single layer screens.
- Highly durable reinforced polyamide construction resists UV degradation and chemical corrosion.
- Easy access housing allows for manual cleaning without the need for specialized tools.
- Low pressure loss design ensures your zones maintain the required PSI for optimal emitter performance.
- Dual Lite configuration provides a larger filtration surface area for high flow applications.
- Corrosion proof materials are compatible with acidic water and common landscape fertilizers.
Common Applications
- Commercial landscape irrigation
- Residential lawn and garden systems
- Agricultural and crop irrigation
- Municipal parks and public spaces
- Greenhouse and nursery operations
- Drip and micro-irrigation headers
Installation Notes
Ensure the filter is installed with the flow arrow pointing in the correct direction and allow for at least ten inches of clearance to remove the filter cover for maintenance. Use high quality PTFE thread sealant on the 2 inch MPT connections to prevent leaks, but avoid over tightening which can stress the housing. We recommend installing a manual blow down valve on the bottom port to allow for quick flushing of heavy sediment during routine site visits.
